VPI-2000 Horizontal Automatic Vacuum Pressure Impregnation Equipment

The VPI-2000 Vacuum Pressure Impregnation (VPI) Equipment, manufactured by WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. , is a high-performance, fully automatic system designed for critical insulation treatment in high-voltage motors, explosion-proof motors, and transformers. This horizontal autoclave utilizes advanced vacuum and pressure technology to significantly enhance the mechanical strength, insulation properties, and resistance to moisture and mildew of workpieces.

Engineered in accordance with strict pressure vessel standards (GB150-1998) and vacuum design standards (JB/T7674-95), this "turn-key" solution ensures complete reliability. The system features a robust construction with a Q345-R steel body and 16MnR heads, designed for a working pressure of 1.0 MPa and an ultimate vacuum of 100 Pa. It integrates a PLC-based control system with a 21-inch LCD screen for real-time monitoring and data logging of parameters such as vacuum, pressure, and tank level. Key components include a high-efficiency three-stage vacuum unit, a temperature-controlled storage tank with a搅拌 system, and both heating and cooling systems to maintain precise resin conditions. Safety is paramount with features like overpressure alarms, mechanical-electrical interlocks, and a hydraulic lid locking mechanism.

Key Technical Specifications:

As your trusted partner, WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. provides a comprehensive package including design, manufacturing, installation, and training. This automatic vacuum impregnation equipment ensures superior resin penetration, making it the ideal choice for demanding industrial applications requiring high-performance motor insulation treatment.
